Triumph SpeedCut 56

22" Hydraulic Paper Cutter

– Electric Paper Cutter
– Cutting Width: 22″
– Cutting Height: 3.14″ / 3.03″
– Length Behind Blade: 28″
– Narrow Cut: <0.59″ / 2.36″
– Clamp Type: Fast-action lever

Product Details

– Blade Material: German steel
– Horsepower: 2
– Electrical Requirements: 120 V. 60 Hz– 20 amp dedicated line required
– Dimensions (D x W x H): 48″ x 39″ x 60″
– Shipping Weight: 668 lbs.

Free Speedcut software download

Features

Electro-mechanical precision blade drive and hydraulic clamp drive (patent pending)

Programmable and manual backgauge positioning with optimum operator ergonomics and logic

Adjustable back gauge with narrow separations and plastic gliders

The precision back gauge spindle guarantees exact cuts.

Clamp bar with infinitely programmable adjustment

Electronically controlled false clamp plate, ideal for delicate work

Infinitely dimmable front table illumination LEDs

Ergonomic control element for manual adjustment of the backgauge position

Table height ergonomically adjustable from 37.4" to 39.37"

Solid steel blade carrier with blade guide system (patent pending)

Accessible blade depth adjustment on the front of the machine (patent-pending)

Integrated tool storage

Specifications

Cutting Width	22"
Cutting Height	3.15" / 3" w/false clamp
Narrow Cut	<.6" / 2.3"
Table Depth	22"
Table Height	adjustable from 37" - 39"
Electrical Requirements	120 V, 60Hz, 20 amp dedicated line required

Product Literature (PDF): Triumph-Speedcut-56.pdf
